Reverse Chassis Engine Coupler

Reverse Chassis Engine Coupler

Reverse Chassis Engine Coupler

Features of Reverse Chassis Engine Coupler:

1. Adopting united water cooling mode, the torque converter sets simplify the whole cooling system, decreasing the assistant power consumption
2. Reasonable structure for easy installation and transport
3. Can be matched with 2000, 3000 and 4000-diesel engine, and is suitable for mud pump of 500-1600HP
4. The slippage of the coupler is adjustable, thus providing protection for the set
5. During the operation, it causes no abrasion and can absorb the shake from the diesel engine, resulting in a longer engine life (increased by 40~60%)

Applications:
It is mainly used to drive the drilling rigs

Specification of Reverse Chassis Engine Coupler:
2000 Reverse Chassis Engine Coupler:
  2012 series Diesel engine parameters Diesel engine model Coupler model Set model Input power of couplers kW Coupling efficiency%
Rpm
r/min
Power
kW
1200 735 G12V190ZL-1 YOTFJ750-22FlshA CO735F-1/22 695    95
1300 810 G12V190ZL-3 YOTFJ750-25FLshA CO810F-3/25 770
1500 900 G12V190ZL YOTFJ750-33FLshA CO900F/33 860
2008 series 1300 510 G8V190PZL-3 YOTFJ750-20FLshA CO510F-3/20 470


3000-Reverse Chassis Engine Coupler:
3000 series
12V
Diesel engine parameters Diesel engine model Coupler model Set model Input power of couplers kW Coupling efficiency%
Rpm
r/min
Power
kW
1200 1000 A12V190ZL-1 YOTFJ750-22Flsh CO1000F-1/22 860 95
1300 1100 A12V190ZL-3 YOTFJ750-25FLsh CO1100F-3/25 1060
1500 1200 A12V190ZL YOTFJ750-33FLsh CO1200F/33 1160
B3000 1500 1360 BH12V190PZL YOTFJ750-33FLsh CO1360F/33 1300 95
1300 510 BH12V190PZL-3 YOTFJ750-25FLsh CO1210-3/25 1150
4012 series 1200 1200 L12V190ZL-1 YOTFJ875-22FLshA CO1200F/22 1200 95
1300 1300 L12V190ZL-3 YOTFJ875-25FLshA CO1300F-3/25 1300
